A simple innovative
high-performance system !

The system

is permanently supplied with mains water connected to a softener

(3)

(single or double depending on the model). The softened water will feed the brine tank

(4)

and the production circuit.

The brine tank (4) is fed by the softened water coming from the softener and allow blending with the salt previously poured at the bottom of the tank. The salt used must comply with one of the 4 standards thereafter : NF EN 973 Quality – NF EN 14805 Type 1 – NF EN 16401 Quality A – NF EN 16370

The dosing pump will inject the brine created at the entrance of the production circuit. This brine is mixed with softened water before entering the production cells.

The mixture obtained is injected into the production cells, through which an electric current flows. Based on the same principle as saltwater chlorination, the cells will create a naturally chlorinated solution: sodium hypochlorite.

The hydrogen lighter than air, generated during production, will be evacuated to the outside of the room with the help of a turbine for models with a production of more than 280 g/h. A hydrogen extraction system is available as an option on models 70 and 140 to complete the safety in the technical room.

The solution created is poured into a storage tank (2) secured by level sensors. The volume of the storage tank varies according to the model. Average concentration: 4 g/L of active chlorine.

The control and production unit (1) controls all the modules. The box controls the production reactor, manages the levels and the safety devices, allows programming the production periods in a simple and intuitive way thanks to a simple menu architecture.

Consult the parameters of your pools remotely be alerted thanks to the two communication systems installed on our devices: Real-time remote information: thanks to the insertion of a SIM card (not supplied) in the system, a set of administrators (pool managers) receive real-time alerts via SMS. Remote pool management with Connect Pro®: thanks to a simple connection to the local network, you can centralize all the information on the operating status of the installations.

A simple innovative
high-performance system !

The system is permanently supplied with mains water connected to a softener (3) (single or double depending on the model). The softened water will feed the brine tank (4) and the production circuit.

The brine tank (4) is fed by the softened water coming from the softener and allow blending with the salt previously poured at the bottom of the tank. The salt used must comply with one of the 4 standards thereafter :
NF EN 973 Quality – NF EN 14805 Type 1 – NF EN 16401 Quality A – NF EN 16370

The dosing pump will inject the brine created at the entrance of the production circuit. This brine is mixed with softened water before entering the production cells.

The mixture obtained is injected into the production cells, through which an electric current flows. Based on the same principle as saltwater chlorination, the cells will create a naturally chlorinated solution: sodium hypochlorite.

The hydrogen lighter than air, generated during production, will be evacuated to the outside of the room with the help of a turbine for models with a production of more than 280 g/h. A hydrogen extraction system is available as an option on models 70 and 140 to complete the safety in the technical room.

The solution created is poured into a storage tank (2) secured by level sensors. The volume of the storage tank varies according to the model. Average concentration: 4 g/L of active chlorine.

The control and production unit (1) controls all the modules. The box controls the production reactor, manages the levels and the safety devices, allows programming the production periods in a simple and intuitive way thanks to a simple menu architecture.

Consult the parameters of your pools remotely be alerted thanks to the two communication systems installed on our devices: Real-time remote information: thanks to the insertion of a SIM card (not supplied) in the system, a set of administrators (pool managers) receive real-time alerts via SMS. Remote pool management with Connect Pro®: thanks to a simple connection to the local network, you can centralize all the information on the operating status of the installations.

A simple innovative
high-performance system !

Consult the parameters of your pools remotely be alerted thanks to the two communication systems installed on our devices : Real-time remote information: thanks to the insertion of a SIM card (not supplied) in the system, a set of administrators (pool managers) receive real-time alerts via SMS.

Remote pool management with Connect Pro®: thanks to a simple connection to the local network, you can centralize all the information on the operating status of the installations.

The system is permanently supplied with mains water connected to a softener (single or double depending on the model). The softened water will feed the brine tank  and the production circuit.
The brine tank is fed by the softened water coming from the softener and allow blending with the salt previously poured at the bottom of the tank. The salt used must comply with one of the 4 standards thereafter :
NF EN 973 Quality
NF EN 14805 Type 1
NF EN 16401 Quality A
NF EN 16370

The dosing pump will inject the brine created at the entrance of the production circuit. This brine is mixed with softened water before entering the production cells.

The mixture obtained is injected into the production cells, through which an electric current flows. Based on the same principle as saltwater chlorination, the cells will create a naturally chlorinated solution: sodium hypochlorite.

The hydrogen lighter than air, generated during production, will be evacuated to the outside of the room with the help of a turbine for models with a production of more than 280 g/h. A hydrogen extraction system is available as an option on models 70 and 140 to complete the safety in the technical room.

The solution created is poured into a storage tank secured by level sensors. The volume of the storage tank varies according to the model. Average concentration: 4 g/L of active chlorine.

The control and production unit controls all the modules. The box controls the production reactor, manages the levels and the safety devices, allows programming the production periods in a simple and intuitive way thanks to a simple menu architecture.

Keep an eye
on your chlorine production !

iPOQLOR® is the ideal solution to these problems in the field !

REAL-TIME VIEW
OF YOUR DEVICE’S

VARIOUS
parameters

HISTORY
of data and alarms

iPOQLOR® EST LA SOLUTION IDÉALE À CES PROBLÉMATIQUES RENCONTRÉES SUR LE TERRAIN !

Physical RJ45 Ethernet connection to access all equipment operating data via the Connect Pro platform (included as standard) :

. Production time

. Sodium hypochlorite solution temperature

. Events

. Alarms

. Graphs

. Production curves (daily, weekly, monthly)

GSM Connection : A dedicated slot for a SIM (not supplied) is provided in the control box.
The user can assign up to 3 telephone numbers to receive any alarms detected by the system by text messages.

Keep an eye on your chlorine production !

IPOQLOR® IS THE IDEAL SOLUTION TO THESE PROBLEMS IN THE FIELS !

REAL-TIME VIEW OF

YOUR DEVICE’S VARIOUS
parameters

HISTORY
of data and alarms

iPOQLOR® EST LA SOLUTION IDÉALE À CES PROBLÉMATIQUES RENCONTRÉES SUR LE TERRAIN !

Physical RJ45 Ethernet connection to access all equipment operating data via the Connect Pro platform (included as standard) :

Production time, Sodium hypochlorite solution temperature, Events, Alarms, Graphs, Production curves (daily, weekly, monthly)

GSM Connection : A dedicated slot for a SIM (not supplied) is provided in the control box.
The user can assign up to 3 telephone numbers to receive any alarms detected by the system by text messages.

Keep an eye
on your chlorine production !

iPOQLOR® IS THE IDEAL SOLUTION TO THESE PROBLEMS IN THE FIELS !

REAL-TIME VIEW OF YOUR

DEVICE’S VARIOUS
parameters

HISTORY
of data and alarms

iPOQLOR® EST LA SOLUTION IDÉALE À CES PROBLÉMATIQUES RENCONTRÉES SUR LE TERRAIN !

Physical RJ45 Ethernet connection to access all equipment operating data via the Connect Pro platform (included as standard) :

Production time, Sodium hypochlorite solution temperature, Events, Alarms, Graphs, Production curves (daily, weekly, monthly)

GSM Connection : A dedicated slot for a SIM (not supplied) is provided in the control box.

The user can assign up to 3 telephone numbers to receive any alarms detected by the system by text messages.

Technical specifications
iPOQLOR® range

Technical specifications

iPOQLOR® range

iPOQLOR models
Reference

iPOQLOR70
PURE22OEM70
iPOQLOR140
PURE22OEM140
iPOQLOR280
PURE22OEM280
Maximum production (L/h) 9 17.5 35
Active chlorine maximum production (g/h) 70 140 280
Active chlorine maximum production per day (kg/day) 1.7 3.4 6.7
Active chlorine concentration (g/L) 6-8 6-8 6-8
Calcium hypochlorite equivalent 68 % (kg/day) 2.5 5 10
Liquid chlorine equivalent 48° chl (L/day) 11 22 44
Hydrogen generation (L/h) 24 48 95
GENERAL CONSUMPTIONS
Water (L/l) 9 17.5 35
Salt (with softener) (g/h) 225 450 900
1 KG ACTIVE CHLORINE PRODUCTION CONSUMPTIONS
Electricity (kW) 3.5 3.5 3.5
Certified biocide salt (kg) 3.1 3.1 3.1
Softened water (L) 125 125 125
CONDITIONS OF USE
Environmental temperature (°C) < 40 < 40 < 40
Input water temperature (°C) < 20 < 20 < 20
Input water hardness (with softener) (°f) < 10 < 10 < 10
Pressure (bar)  1 à 3  1 à 3  1 à 3
CARACTERISTICS
Frame dimensions (WxDxH mm) 765 x 717 x 230 765 x 717 x 230 765 x 2050 x 655
Weight (kg) 70 70 150
Production tank and retention tank material  UV-treated polyethylene  UV-treated polyethylene  UV-treated polyethylene
Prodction tank volume (L) 100 100 250
Brine tank volume (L) 100 100 200
Softener resin volume (L) 4 4 15
ELECTRICAL SPECIFICATIONS
General supply 230 V – 50/60 Hz 230 V – 50/60 Hz 230 V – 50/60 Hz
Internal circuit breaker rating (A) 6 6 12
Section of the general supply cable 3G 1,5 3G 1,5 3G 2,5
Length of main power cable (m) 2.5 2.5 2.5
Maximum power (kW) 0.4 0.8 1.6
Mains current rating (A) 1.25 2.5 5
Maximum current on mains (A) 2,1 4.2 8.4
Maximum current on each electrode (A) < 20 < 20 < 20
Voltage on each electrode (V) < 20 < 20 < 20
EQUIPMENTS / FEATURES
Number of electrodes 1 2 4
Operation modes Automatic and programmable operating ranges Automatic and programmable operating ranges Automatic and programmable operating ranges
Communication SMS alerts – Connect Pro remote control SMS alerts – Connect Pro remote control SMS alerts – Connect Pro remote control
